3D measurement of an object. Close-up of a coordinate measurement machine (top, black) measuring the dimensions of a small sphere (pink, centre) mount
RMID:Image ID:2ACGBXF
Image details
Contributor:
Science Photo LibraryImage ID:
2ACGBXFFile size:
55.1 MB (947.1 KB Compressed download)Releases:
Model - no | Property - noDo I need a release?Dimensions:
4614 x 4174 px | 39.1 x 35.3 cm | 15.4 x 13.9 inches | 300dpiDate taken:
22 January 2010More information:
3D measurement of an object. Close-up of a coordinate measurement machine (top, black) measuring the dimensions of a small sphere (pink, centre) mounted on a holder. Machines like this are capable of accurate 3D measurements of complex, precision-engineered components such as fuel injection nozzles. This machine has both a touch-sensitive probe, and an optical probe located on the same probe head (silver, above black sphere). Photographed at the National Physical Laboratory, Teddington, England.
